APR CPS Radiator - B8/B8.5 3.0T/4.0T
Regular price
$1,599.95
Sale price
$1,438.95
APR CPS Radiator - B8/B8.5 3.0T/4.0T
Regular price
$1,599.95
Sale price
$1,438.95
APR Part Number: MS100127
Fits 2012-2018 Audi A6/A7 Quattro - 2013-2017 Audi Q5 - 2010-2016 Audi S4/S5 - 2013-2018 Audi S6/S7 - 2014-2017 Audi SQ5
APR availability: Est. Ship Date: 10/30/2026
Overview
The APR Coolant Performance System (CPS) is a massive front-mounted cooler upgrade that dramatically reduces intake air temperature (IAT), minimizes heat soak, and provides increased performance! It is 140% larger than the stock B8 unit and features a self-bleeding cooling circuit to ensure it is always operating at peak performance. The system is easy to maintain and fully integrated into the factory cooling circuit. This upgrade is highly recommended at every stage!
Features:
- Dramatically lowers intake air temp (IAT)
- Increases and retains HP while minimizing power-robbing heat soak!
- Massive frontal surface area (core) and volume (radiator)
- 29" x 05.5" x 2.1" - 159.5"² & 054"³ - OEM
- 22" x 17.4" x 1.7" - 382.8"² & 130"³ - APR
- Highly effective dual-pass core design
- Tightly packed external louvered fins rapidly dissipate heat as coolant flows through internal cooling paths.
- Self-bleeding and self-optimizing system
- Air-bubbles trapped within the system kills performance!
- The self-bleeding system constantly removes air from the system, without any manual intervention!
- Retains factory safety and control
- The ECU retains full control over the system, protecting against pump failure and coolant leaks.
- Easy to install and maintain
- All the performance without the headaches. Each system is fully pressure tested after assembly.
Specifications
| Brand | APR |
|---|---|
| Category | Belts and Cooling |
| Color | Silver / Natural |
| Cooler Type | Air to Water |
| Core Frontal Area | 382.80 SI |
| Core Height | 17.4 IN |
| Core Type | Tube and Fin |
| Core Volume | 650.76 CI |
| Core Width | 1.7, 22 IN |
| Direct Fit | Yes |
| Emission Code | 6 |
| Product Type | Intercooler Systems |
| Sub Category | Radiators, Coolers and Related Components |
| Welding Type | TIG |
| UPC | 810904031228 |
| Part Number | MS100127 |
Tech Resources
Please note, the B8 S4/S5 and some C7 A6/A7 require the CPS Fit Kit (MS100136). The fit kit is required when the cooler has an inlet and outlet on opposite sides. Furthermore, some B8 S4/S5 vehicles with Audi Drive Select (ADS) coolers will require custom relocation of the cooler. This cooler is a U shaped cooling fin system visible through the top of the grille.
Vehicle Applications
- 2013–2015 Audi S7 — 4.0L; United States
- 2016–2018 Audi S7 (C7.5, 4G8) — 4.0L; United States
- 2012–2015 Audi A7 — 3.0L; United States
- 2016–2016 Audi A7 (C7.5, 4G8) — 3.0L; United States
- 2017–2018 Audi A7 (C7.5, 4G8) — 3.0L; United States
- 2014–2015 Audi SQ5 — 3.0L; United States
- 2016–2017 Audi SQ5 (8R) — 3.0L; United States
- 2010–2015 Audi S5 — 3.0L; United States
- 2016–2017 Audi S5 (B8.5, 8T, 8F) — 3.0L; United States
- 2013–2015 Audi Q5 — 3.0L; United States
- 2016–2016 Audi Q5 (8R) — 3.0L; United States
- 2017–2017 Audi Q5 (8R) — 3.0L; United States
- 2010–2015 Audi S4 — 3.0L; United States
- 2016–2016 Audi S4 (B8.5, 8K) — 3.0L; United States
- 2012–2015 Audi A6 — 3.0L; United States
- 2016–2016 Audi A6 (C7.5, 4G) — 3.0L; United States
- 2017–2018 Audi A6 (C7.5, 4G) — 3.0L; United States
- 2013–2015 Audi S6 — 4.0L; United States
- 2016–2018 Audi S6 (C7.5, 4G) — 4.0L; United States
Fitment Requirements
Please note, the B8 S4/S5 and some C7 A6/A7 require the CPS Fit Kit (MS100136). The fit kit is required when the cooler has an inlet and outlet on opposite sides. Furthermore, some B8 S4/S5 vehicles with Audi Drive Select (ADS) coolers will require custom relocation of the cooler. This cooler is a U shaped cooling fin system visible through the top of the grille.
Instructions - ms100127_30tfsi_40t_cps.pdf Please note, the B8 S4/S5 and some C7 A6/A7 require the CPS Fit Kit (MS100136). The fit kit is required when the cooler has an inlet and outlet on opposite sides. Furthermore, some B8 S4/S5 vehicles with Audi Drive Select (ADS) coolers will require custom relocation of the cooler. This cooler is a U shaped cooling fin system visible through the top of the grille.
