APR A02 Flow Formed Wheels (20x9.0) (Satin Black) (1 Wheel)
Regular price
$449.95
Sale price
$403.95
APR A02 Flow Formed Wheels (20x9.0) (Satin Black) (1 Wheel)
Regular price
$403.95
Regular price
$449.95
Sale price
$403.95
Unit price
per
APR A02 Flow Formed Wheels (20x9.0) (Satin Black) (1 Wheel)
Regular price
$449.95
Sale price
$403.95
APR Part Number: WHL00036
APR A02 - Flow Formed - 20x9.0 - ET37 - 5x112 - Satin Black
APR availability: Est. Ship Date: 11/13/2026
Overview
APR A02 Flow Formed Wheels pay homage to several classic wheels in a new and unique design that is sure to turn heads! Central to the wheel is a classic 5-spoke pattern that has been hollowed out for weight savings and interlaced inside of a 5-spoke Y pattern that pays respect to the APR A01 wheels. The meshing together of these two iconic designs brings together a snow flake pattern we all love from decades past.
The wheels are flow formed, which means they are strong and light weight, yet cost dramatically less then forged wheels. Finite Element Analysis (FEA) was used to reduce spoke width to reduce weight while providing the strength necessary to achieve a 720 KG load rating. Furthermore, weight saving pockets are cut behind the wheel face to reduce weight.
Strong billet aluminum CNC-machined rings allow the wheels to be compatible with both common center bores, and won't wobble, crack, or crumble like other materials. The center caps are removable and upgradeable and are even compatible with various OEM center caps for a stealth look! The lug bolts are compatible with OEM ball seat lugs, and the barrel has anti-slip machining features to prevent tire-to-wheel rotation.
The A02 wheels are offered in various widths, diameters, offsets, and colors.
Features:
- Satin Black wheel color
- 20 x 9.0" ET37
- Flow-formed aluminum construction for an extreme weight to strength ratio at an affordable price
- 11kg light weight design with weight saving pockets behind the wheel face
- 5x112mm bolt pattern fits most Audi, Seat, Skoda, and VW Vehicles from 2005+
- Fits both common VAG center bores (66.5mm and 57.1mm)
- Billet aluminum CNC-machined center locking rings which prevent wobble, cracking and crumbling like other materials
- Tested to SAE J2530 and VIA/JWL specifications
- Compatible with various OEM Audi, Seat, Skoda, and VW center-caps (VW 7L6601149B & Audi 8T0601170A)
- Compatible with OEM-style and length ball seat lug bolts
- Ant-Slip machining on the barrel to prevent tire-to-wheel rotation
- Finite Element Analysis (FEA) designed to minimize weight, yet retain a 720 KG load rating
Specifications
| Bolt Pattern | 5x112 |
|---|---|
| Brand | APR |
| Category | Tire and Wheel |
| Center Bore | 66.5 MM |
| Center Bore with Insert | 57.1 MM |
| Certifications | SAE J2530 and VIA/JWL |
| Color | Satin Black |
| Construction | Flow Formed |
| Diameter | 20 IN |
| Emission Code | 6 |
| ET | 37 |
| Material | A356 Aluminum |
| Product Type | Wheels |
| Quantity | 1 |
| Sub Category | Wheel |
| Version | A02 |
| Width | 9 IN |
| UPC | 810009933786 |
| Part Number | WHL00036 |
Tech Resources
Please note: Wheels are non-returnable after tires have been mounted. Vehicle application data is a general guideline only. Modifications to suspension and brake calipers may impact fitment. Always check and verify widths, offsets, brake caliper clearance, and other aspects for proper fitment. APR Wheel Spacers are available where necessary.
Vehicle Applications
- 2015–2015 Porsche Macan; United States
- 2025–2026 Porsche Macan; United States
- 2016–2018 Porsche Macan (95B); United States
- 2019–2021 Porsche Macan (95B.2); United States
- 2022–2024 Porsche Macan (95B.3); United States
- 2013–2015 Audi S7; United States
- 2016–2018 Audi S7 (C7.5, 4G8); United States
- 2012–2015 Audi A7; United States
- 2016–2018 Audi A7 (C7.5, 4G8); United States
- 2013–2015 Audi RS 5; United States
- 2018–2019 Audi RS 5 (B9, F5); United States
- 2021–2024 Audi RS 5 (B9.5, F5); United States
- 2015–2015 Audi Q3; United States
- 2016–2018 Audi Q3 (8U); United States
- 2019–2026 Audi Q3 (F3); United States
- 2014–2015 Audi SQ5; United States
- 2016–2017 Audi SQ5 (8R); United States
- 2018–2025 Audi SQ5 (FY, MLB-EVO); United States
- 2026–2026 Audi SQ5 (PPC); United States
- 2014–2015 Audi RS 7; United States
- 2016–2018 Audi RS 7 (C7.5, 4G8); United States
- 2006–2013 Audi A3; United States
- 2015–2015 Audi A3; United States
- 2016–2020 Audi A3 (8V); United States
- 2022–2024 Audi A3 (8Y); United States
- 2013–2016 Audi A4 allroad; United States
- 2017–2025 Audi A4 allroad; United States
- 2016–2018 Audi A3 Sportback e-tron; United States
- 2018–2023 Audi A5 Sportback; United States
- 2018–2025 Audi S5 Sportback; United States
- 2017–2020 Audi RS 3 (8V); United States
- 2022–2026 Audi RS 3 (8Y); United States
- 2019–2019 Audi RS 5 Sportback; United States
- 2021–2025 Audi RS 5 Sportback; United States
- 2019–2019 Audi e-tron (GE, MLB-EVO); United States
- 2021–2023 Audi e-tron (GE, MLB-EVO); United States
- 2022–2026 Audi Q8 (4M8, MLB-EVO); United States
- 2019–2025 Audi A7 Sportback; United States
- 2009–2015 Audi TTS; United States
- 2016–2023 Audi TTS (8S, FV); United States
- 2012–2013 Audi TT RS; United States
- 2018–2022 Audi TT RS (8S, FV); United States
- 2020–2023 Audi e-tron Sportback; United States
- 2020–2026 Audi A6 allroad; United States
- 2020–2025 Audi S7 Sportback; United States
- 2022–2026 Audi RS Q8 (4M8, MLB-EVO); United States
- 2020–2025 Audi Q5 PHEV; United States
- 2021–2026 Audi RS 6 Avant; United States
- 2022–2026 Audi SQ8 (4M8, MLB-EVO); United States
- 2022–2026 Audi SQ7 (4M, MLB-EVO); United States
- 2022–2026 Audi Q7 (4M, MLB-EVO); United States
- 2007–2008 Audi RS 4; United States
- 2021–2026 Audi RS 7 Sportback; United States
- 2021–2026 Audi Q5 Sportback; United States
- 2021–2026 Audi SQ5 Sportback; United States
- 2022–2026 Audi Q4 e-tron (F4, MEB); United States
- 2022–2026 Audi Q4 e-tron Sportback; United States
- 2022–2023 Audi e-tron S; United States
- 2022–2023 Audi e-tron S Sportback; United States
- 2024–2024 Audi Q8 e-tron (GE, MLB-EVO); United States
- 2024–2024 Audi SQ8 e-tron (GE, MLB-EVO); United States
- 2024–2025 Audi SQ8 e-tron Sportback; United States
- 2008–2015 Audi A5; United States
- 2016–2017 Audi A5 (B8.5, 8T, 8F); United States
- 2018–2020 Audi A5 (B9, F5); United States
- 2021–2026 Audi A5 (B9.5, F5); United States
- 2008–2015 Audi S5; United States
- 2016–2017 Audi S5 (B8.5, 8T, 8F); United States
- 2018–2020 Audi S5 (B9, F5); United States
- 2021–2026 Audi S5 (B9.5, F5); United States
- 2009–2015 Audi Q5; United States
- 2016–2017 Audi Q5 (8R); United States
- 2018–2025 Audi Q5 (FY, MLB-EVO); United States
- 2026–2026 Audi Q5 (PPC); United States
- 2015–2015 Audi S3; United States
- 2016–2020 Audi S3 (8V); United States
- 2022–2024 Audi S3 (8Y); United States
- 2010–2014 Audi A5; United States
- 1992–1994 Audi S4; United States
- 2000–2002 Audi S4; United States
- 2004–2015 Audi S4; United States
- 2016–2016 Audi S4 (B8.5, 8K); United States
- 2018–2019 Audi S4 (B9, 8W); United States
- 2020–2025 Audi S4 (B9.5, 8W); United States
- 1995–2004 Audi A6; United States
- 2006–2015 Audi A6; United States
- 2016–2018 Audi A6 (C7.5, 4G); United States
- 1995–2015 Audi A6; United States
- 2019–2025 Audi A6 (C8, 4K); United States
- 2026–2026 Audi A6 (C9, PPC); United States
- 1995–1995 Audi S6; United States
- 2002–2003 Audi S6; United States
- 2007–2011 Audi S6; United States
- 2013–2015 Audi S6; United States
- 2016–2018 Audi S6 (C7.5, 4G); United States
- 2020–2025 Audi S6 (C8, 4K); United States
- 1996–2015 Audi A4; United States
- 2016–2016 Audi A4 (B8.5, 8K); United States
- 2017–2019 Audi A4 (B9, 8W); United States
- 2020–2020 Audi A4 (B9.5, 8W); United States
- 2020–2025 Audi A4 (B9.5, 8W); United States
- 1997–1999 Audi A8; United States
- 1997–2015 Audi A8; United States
- 2016–2018 Audi A8 (D4.5, 4H); United States
- 2019–2026 Audi A8 (D5, 4N); United States
- 2008–2009 Audi TT; United States
- 2008–2015 Audi TT; United States
- 2016–2023 Audi TT (8S, FV); United States
- 2001–2005 Audi A6 allroad; United States
- 2001–2003 Audi S8; United States
- 2007–2009 Audi S8; United States
- 2013–2015 Audi S8; United States
- 2016–2018 Audi S8 (D4.5, 4H); United States
- 2020–2026 Audi S8 (D5, 4N); United States
- 2003–2003 Audi RS 6; United States
- 2004–2006 Volkswagen Phaeton; United States
- 2015–2015 Volkswagen e-Golf; United States
- 2016–2019 Volkswagen e-Golf (5G, MQB); United States
- 2015–2015 Volkswagen Golf SportWagen; United States
- 2016–2019 Volkswagen Golf SportWagen (5G, MQB); United States
- 2012–2013 Volkswagen Golf R; United States
- 2015–2015 Volkswagen Golf R; United States
- 2016–2019 Volkswagen Golf R (5G, MQB); United States
- 2022–2026 Volkswagen Golf R (CD, MQB-EVO, Mk8); United States
- 2017–2019 Volkswagen Golf Alltrack (5G, MQB); United States
- 2018–2026 Volkswagen Atlas (CA1, MQB); United States
- 2017–2018 Volkswagen Tiguan Limited; United States
- 2019–2023 Volkswagen Arteon (3H, MQB); United States
- 2020–2026 Volkswagen Atlas Cross Sport (CA1, MQB); United States
- 2022–2026 Volkswagen Taos (CP, MQB-A1); United States
- 2021–2023 Volkswagen ID.4 (E21, MEB); United States
- 2007–2015 Volkswagen Eos; United States
- 2016–2016 Volkswagen Eos (1F, PQ35); United States
- 2008–2008 Volkswagen R32; United States
- 2009–2015 Volkswagen Tiguan; United States
- 2016–2017 Volkswagen Tiguan (5N, PQ35); United States
- 2018–2024 Volkswagen Tiguan (BW, MQB); United States
- 2025–2026 Volkswagen Tiguan (MQB-EVO); United States
- 2006–2015 Volkswagen Golf GTI; United States
- 2016–2021 Volkswagen Golf GTI (5G, MQB); United States
- 2022–2026 Volkswagen Golf GTI (CD, MQB-EVO, Mk8); United States
- 2009–2015 Volkswagen CC; United States
- 2016–2017 Volkswagen CC (3C8, PQ46); United States
- 2012–2015 Volkswagen Beetle; United States
- 2016–2019 Volkswagen Beetle (5C, PQ35); United States
- 2006–2009 Volkswagen Rabbit; United States
- 2005–2015 Volkswagen Jetta; United States
- 2016–2018 Volkswagen Jetta (A6, NCS, 16); United States
- 2019–2026 Volkswagen Jetta (A7, BU, MQB); United States
- 2010–2015 Volkswagen Golf; United States
- 2016–2021 Volkswagen Golf (5G, MQB); United States
- 2006–2010 Volkswagen Passat; United States
- 2012–2015 Volkswagen Passat; United States
- 2016–2022 Volkswagen Passat (NMS, A32); United States
Fitment Requirements
Please note: Wheels are non-returnable after tires have been mounted. Vehicle application data is a general guideline only. Modifications to suspension and brake calipers may impact fitment. Always check and verify widths, offsets, brake caliper clearance, and other aspects for proper fitment. APR Wheel Spacers are available where necessary.
Instructions - whl00001_whl00002_apr_wheels_balancing.pdf Please note: Wheels are non-returnable after tires have been mounted. Vehicle application data is a general guideline only. Modifications to suspension and brake calipers may impact fitment. Always check and verify widths, offsets, brake caliper clearance, and other aspects for proper fitment. APR Wheel Spacers are available where necessary.
